CPU
AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ 3rd Gen Ryzen™ a 3rd Gen Ryzen™ s Radeon™ Graphics Processors
(Please refer "CPU Support List" pre viac informácií.)
Chipset
AMD A520
Memory
2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
3rd Gen AMD Ryzen™ Processors:
Support for DDR4 5100 ( OC ) / 5000 ( OC ) / 4866 ( OC ) / 4600 ( OC ) / 4400 ( OC ) / 4000 ( OC ) / 3600 ( OC ) / 3333 ( 3 ) 2667 / 2400 / 2133 MHz memory modules
3rd Gen AMD Ryzen™ s Radeónom™ Graphics processors:
Support for DDR4 5100 ( OC ) / 5000 ( OC ) / 4866 ( OC ) / 4600 ( OC ) / 4400 ( OC ) / 4000 ( OC ) / 3600 ( OC ) / 3333 ( 3 ) 2667 / 2400 / 2133 MHz memory modules
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
(Please refer "Memory Support List" pre viac informácií.)
Onboard Graphics
Integrovaný v 3. generácii AMD Ryzen™ s Radeónom™ Graphics processors:
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz

• Port DVI-D nie je podporovaný D-Sub connection by adaptér.
  1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

• Support pre HDMI 2.1 verziu, HDCP 2.3, a HDR.
  Support for up to 3 displays at the same time
  Maximum shared memory of 16 GB
  Audio
  Realtek® ALC887 kódec
  High Definition Audio
  2/4/5.1/7.1-channel

• To configure 7.1-channel audio, budete potrebovať otvorený zvukový softvér a vyberte Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website pre detaily on configuring the audio software.
  LAN
  Realtek® GbE LAN chip (1000 Mbit/100 Mbit)
  Expansion Slots
  CPU:
  1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
  Chipset:
  2 x PCI Express x1 slots, supporting PCIe 3.0
  Storage Interface
  CPU:
  1 x M.2 connector (Socket 3, M key, typ 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
  Chipset:
  4 x SATA 6Gb/s konektory
  Support for RAID 0, RAID 1, and RAID 10
  USB
  CPU:
  4 x USB 3.2 Gen 1 ports on the back panel
  Chipset:
  2 x USB 3.2 Gen 1 ports dostupný prostredníctvom vnútorného USB headeru
  6 x USB 2.0/1.1 ports (2 porty na zadnom paneli, 4 porty dostupné cez vnútorné USB headers)
  Internal I/O Connectors
  1 x 24-pin ATX main power connector
  1 x 8-pin ATX 12V power connector
  1 x CPU fan header
  2 x system fan headers
  1 x addressable LED strip header
  1 x RGB LED strip header
  1 x M.2 Socket 3 konektor
  4 x SATA 6Gb/s konektory
  1 x front panel header
  1 x front panel audio header
  1 x USB 3.2 Gen 1 header
  2 x USB 2.0/1.1 headers
  1 x Trusted Platform Module (TPM) header (2x6 pin, pre modul GC-TPM2.0_S only)
  1 x serial port header
  1 x speaker header
  1 x chassis intrusion header
  1 x Clear CMOS jumper
  Back Panel Connectors
  1 x PS/2 keyboard/mouse port
  1 x D-Sub port
  1 x DVI-D port
  1 x HDMI port
  4 x USB 3.2 Gen 1 ports
  2 x USB 2.0/1.1 ports
  1 x RJ-45 port
  1 x Q-Flash Plus button
  3 x audio jacks
  I/O Controller
  iTE® I/O Controller Chip
  H/W Monitoring
  Voltage detection
  Temperature detection
  Fan speed detection
  Overheating warning
  Fan fail warning
  Fan speed control

• Kým fan speed control function je supported bude depend on the fan you install.
  BIOS
  1 x 128 Mbit flash
  Use of licensed AMI UEFI BIOS
  PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  Unique Features
  Support for APP Center

• Available applications in APP centrum má vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
  @BIOS
  EasyTune
  Fast Boot
  Game Boost
  ON/OFF Charge
  RGB Fusion
  Smart Backup
  System Information Viewer
  Support for Q-Flash Plus
  Support for Q-Flash
  Support for Xpress Install
  Bundled Software
  Norton® Internet Security (OEM version)
  Realtek® 8118 Gaming LAN Bandwidth Control Utility
  Operating System
  Support for Windows 10 64-bit
  Form Factor
  Micro ATX Form Factor; 24.4cm x 20.5cm
