CHIPSET INTEL B760
CPU Support Intel Core 14th, 13th, 12th Gen Processors, Intel Pentium Gold and Celeron Processors
LGA 1700
MEMORY 4x DDR5, Maximum Memory Capacity 192GB
Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ (JEDEC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 6800+ MHz
• 1DPC 2R Max speed up to 6400+ MHz
• 2DPC 1R Max speed up to 6000+ MHz
• 2DPC 2R Max speed up to 5600+ MHz

Supports Intel® XMP 3.0 OC
Supports Dual-Controller Dual-Channel mode
Supports non-ECC, un-buffered memory

ONBOARD GRAPHICS 1x HDMI™
Support HDMI™ 2.1 s HDR, maximum resolution of 4K 60Hz*
1x DisplayPort
Support DP 1.4, maximum resolution of 4K 60Hz*
*Available only on processors integrated graphics. Graphics specifications majú vary depending on the CPU inštalované.
SLOT 5x PCI-E x16 slot
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E5 Gen PCIe 3.0 supports up to x1 (From Chipset)
STORAGE 2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
4x SATA 6G

• SATA8 môže byť unavailable pri inštalácii M.2 SATA SSD v M2_2 slot.
  RAID Supports RAID 0, RAID 1, RAID 5 a RAID 10 pre SATA storage devices
  USB 4x USB 2.0 (Rear)
  4x USB 2.0 (Front)
  2x USB 3.2 Gen1 Type A (Front)
  1x USB 3.2 Gen1 Type C (Front)
  2x USB 3.2 Gen2 Type A (Rear)
  1x USB 3.2 Gen2 Type C (Rear)
  LAN Realtek® RTL8125BG 2.5G LAN
  WIRELESS LAN & BLUETOOTH Intel® Wi-Fi 6E
  The Wireless module je preinštalovaný v M.2 (Key-E) slot
  Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) až 2.4Gbps
  Supports 802.11 a/ b/ g/ n/ ac/ ax

  Supports Bluetooth® 5.3, FIPS, FISMA


• Wi-Fi 6E 6GHz má depend on every country's regulations and will be ready in Windows 11.
  ** Bluetooth 5.3 bude ready in Windows 10 budova 21H1 a Windows 11.
  AUDIO Realtek® ALC897 Codec
  7.1-Channel High Definition Audio
  Supports S/PDIF output
  INTERNAL IO 1x Power Connector(ATX_PWR)
  2x Power Connector(CPU_PWR)
  1x CPU Fan
  1x Pump Fan
  5x System Fan
  2x Front Panel (JFP)
  1x Chassis Intrusion (JCI)
  1x Front Audio (JAUD)
  1x Printer Port (JLPT)
  1x Com Port (JCOM)
  1x TBT konektor (JTBT, supports RTD3)
  2x Addressable V2 RGB LED konektor (JARGB_V2)
  1x RGB LED connector (JRGB)
  1x TPM pin header (Support TPM 2.0)
  4x USB 2.0 ports
  2x USB 3.2 Gen1 Type A ports
  1x USB 3.2 Gen1 Type C ports
  LED FEATURE 4x EZ Debug LED
  BACK PANEL PORTS
  Keyboard / Mouse
  DisplayPort
  2.5G LAN
  USB 2.0
  Wi-Fi / Bluetooth
  Audio Connectors
  USB 2.0
  HDMI™
  USB 3.2 Gen 2 10Gbps (Type-A)
  USB 3.2 Gen 2 10Gbps (Type-C)
  S/PDIF-OUT

  OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
  PCB INFO ATX
  243.84mmx304.8mm
