D-Link DGS-108 kovový 8-port 10/100/1000 Switch

OVERVIEW DGS-108 8-Port Gigabit Nemanaged Desktop Switch offers economical way for SOHO a malé a médiá podnikajú na získanie z rozšíreného bandwidth of Gigabit Ethernet. Je to osem gigabitových portov pre easy expansion vašej siete a rýchlym spôsobom na upgrade vašej siete na gigabit connectivity.

SPECIFICATIONS KEY FEATURES

• Built-in D-Link Green Technology
• Inexpensive Gigabit Solution for Home/SOHO
• Eight 10/100/1000 Mbps Gigabit ports
• 16 Gbps switching fabric
• Auto MDI/MDIX crossover pre všetky porty
• Secure store-and-forward switching scheme
• Full/half-duplex for Ethernet/Fast Ethernet speeds
• IEEE 802.3x Flow Control
• Supports 9,000 Byte Jumbo Frames
• Supports IEEE 802.1p QoS (4 Queues, Strict Mode)
• Supports Cable Diagnostics Function
• RoHS compliant
• Plug-and-play installation
• IGMP Snooping - multicast video / IPTV

ŠTANDARDS

• IEEE 802.3 10BASE-T Ethernet (twistedpair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-pair copper)
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x Flow Control
• IEEE 802.1p QoS
• IEEE 802.3az Energy-Efficient Ethernet (EEE)

PROTOCOL

• CSMA/CD

DÁTA TRANSFER RATES

• Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
• Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
• Gigabit Ethernet: 2000 Mbps (full duplex)

TOPOLOGY

• Star

NETWORK CABLES

• 10BASE-T: UTP CAT 3, 4, 5/5e (100 m max.), EIA/TIA-586 100-ohm STP (100 m max.)
• 100BASE-TX, 1000BASE-T: UTP CAT 5/5e (100 m max.), EIA/TIA-568 100-ohm STP (100 m max.)

MEDIA INTERFÁCIA EXCHANGE

• Auto MDI/MDIX adjustment for all ports

LED INDICATORS

• Per port: Link/Activity/Speed
• Per device: Power

TRANSMISSION METHOD

• Store-and-forward

MAC ADDRESS TABLE

• 8K

MAC ADDRESS LEARNING

• Automatic update

PACKET FILTERING/FORWARDING RATES

• Ethernet: 14,880 pps na port
• Fast Ethernet: 148,800 pps na port
• Gigabit Ethernet: 1,488,000 pps per port

RAM BUFFER

• 128 KB per device

DC INPUT

• External 5 V/1 A Level „V“ Power Adapter

POWER CONSUMPTION

• Power On (Standby): DC vstup: 0.55W, AC vstup: 1.0W
• Maximum: DC vstup: 2.8W, AC vstup: 4.5W

HEAT DISSIPATION

• Power On (Standby): AC vstup 3.41 BTU/h
• Maximum: DC input 9.548 BTU/h

MTBF

• 2,053,751 hours

OPERATING TEMPERATURE

• 0 až 50 °C

STORAGE TEMPERATURE

• -10 až 70 °C

OPERATING HUMIDITY

• 10% to 90% RH non-condensing

STORAGE HUMIDITY

• 5% až 90% RH non-condensing

DEVICE DIMENSIONS (WXDXH)

• 162 x 102 x 28 mm

CERTIFICATIONS

• FCC Class B
• ICES-003 Class B
• CE Class B
• C-Tick Class B
• VCCI Class B
• cUL
• CB
