Chipset: AMD A520

Rozmerový formát: Micro-ATX Form Factor (236 mm x 200 mm)
Podpora pre procesory: AMD Ryzen™ 5000 & 3000 Series desktop processors
Pätica procesora: AM4

Pozícia na pamäti: 2x DDR4 DIMM
Podpora pre pamäte:
•1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
•2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE

Max.veľkosť operačnej pamäte: 64 GB
Podpora pre pamäte typu: DDR4
•Dual channel memory architecture
•Supports non-ECC UDIMM memory
•Supports ECC UDIMM memory (non-ECC mode)
•Supports un-buffered memory

Grafická karta:
•Integrated Graphics Processor (na základe procesora)

Zvuková karta:
• Realtek® ALC892/ALC897 Codec

Sieťová karta:
•1x Realtek® RTL8111H Gigabit LAN controller

Rozširujúce sloty:
•1x PCIe 3.0 x1 slot
•1x PCIe x16 slot

RAID radič: 0, 1, 10

SATA:
•4x SATA 6Gb/s

M.2 :
•1x M.2 slots

USB:
•zadné USB porty (celkom 6)
•2x USB 2.0 ports
•4x USB 3.2 Gen 1 5Gbps Type-A ports
•predné USB porty ( celkom 6 )
•2x USB 3.2 Gen 1 5Gbps ports
•4x USB 2.0 ports

Interné porty:
•1x 24-pin ATX main power connector
•1x 4-pin ATX 12V power connector
•4x SATA 6Gb/s konektory
•1x M.2 slots (M-Key)
•1x USB 3.2 Gen 1 5Gbps konektor (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
•2x USB 2.0 konektory (supports additional 4 USB 2.0 ports)
•1x 4-pin CPU fan connector
•1x 4-pin system fan connectors
•1x Front panel audio connector
•2x System panel connectors
•1x Chassis Intrusion connector
•1x TPM module connector
•1x Clear CMOS jumper

Externé porty:
•LAN port
•HDMI
•DVI-D
•Keyboard / Mouse
•4x USB 3.2 Gen 1 5Gbps Type-A
•2x USB 2.0 Ports
•Audio Connectors
